SGS approval PLC System PBT Plastic Dryer Machine

1set
MOQ
USD 10,000-USD30,000
Price
SGS approval PLC System PBT Plastic Dryer Machine
Features Gallery Product Description Request A Quote
Features
Specifications
Applied For: PBAT ,PLA, PET, APET, APET, GPET, CPET, PLA, HIPS, PE, ABS, EVA ,PC, PEEK, PPS, PTFE, PEEK, TPU, TPE
Drying Temperature: Can Be Adjustable By Material Property
Drying Time: 20mins (can Be Adjustable By Moisture Need)
Power Consumpron: Only 45% Of Conventional Dehumidifier
Processing: Dry And Crystallization At A Time
Heater: Infrared Lamps
Power Source: 380V 50hz 3PHASE Or Customized
Control System: Siemens PLC
Delivery Time: 30 Working Days
Certificate: CE,IS09001, SGS
Applicable Industy: Plastic Moulding
High Light:

PBT Plastic Dryer Machine

,

PLC System Plastic Dryer Machine

,

SGS PBT Dryer Machine

Basic Infomation
Place of Origin: CHINA
Brand Name: LIANDA
Certification: CE,SGS,ISO9001
Model Number: LDHW-100
Payment & Shipping Terms
Packaging Details: Factory standard package or customized package
Delivery Time: 40 working days
Payment Terms: L/C, T/T, Western Union
Product Description

PBT Dryer machine, plastic dehumidifying dryer,dehumidify dryer supplier



I

Processing Explanation



  • Dry and crystallize of amorphous Co-PBT and Co-PET Pellets to 500ppm
  • Process temperature 80 °C to 135 °C
  • Cooling the pellets to 40°C

(Re-cooling the pellets to avoid the pellets re-moistured )

  • Transfer to bagging package



Our IRD ( Infrared Dryer ) will make for you

  • Infrared rotary dryer is designed with sophisticated temperature measurement. The material and exhaust air temperature are continuously monitored by sensors. If there is any deviations,PLC system will adjust automatically
  • There are flexible 5 zone heating control
  • Adopt drum rotation will make sure the constant movement of the raw material to avoid clumping/sticking and dry evenly
  • Within 15mins to get the moisture 500ppm or less ( Depends on customer’s requirement)
  • To get the crystallization level at 20%-30% of the pellets without lumping/sticking)
  • Comprehensive visualization of all process parameters
  • Cooling the pellets to 40°C

(Re-cooling the pellets to avoid the pellets re-moistured )

Our Advantage





Infrared Crystal Dryer



Conventional Crystallizer
1

Easy to clean

The drum can be opened completely,no hidden spots and can be cleaned easily with a vacuum cleaner

Have to be completely disassembled,cleaned and fixed
2 Rotary drying system, its rotating speed can be increased as high as possible to get an excellent mixing of pellets. It is good in agitation, the masterbatch will not be clumped Poor agitation,easy to be clumped
3 Can satisfy different type of Masterbatch (Drying temperature and time can be adjustable by the property of raw material) The drying temperature is fixed
4 Crystallization time 15-20mins depends on the material kind Need 4-6 hours or more
5

Save about 40% energy consumption compared to conventional dehumidifier







SGS approval PLC System PBT Plastic Dryer Machine 0



How Lianda Infrared dryer to crystallize

SGS approval PLC System PBT Plastic Dryer Machine 1



SGS approval PLC System PBT Plastic Dryer Machine 2











SGS approval PLC System PBT Plastic Dryer Machine 3



HOW TO ENSURE THE QUALITY!

● In order to ensure the accuracy of each part, we are equipped with a variety of professional processing equipment and we have accumulated professional processing methods over the past years.
● Each component before assembly needs strictly control by inspecting personnel.
● Each assembly is in charged by a master who has working experience for more than 20 years
●After all the equipment are completed, we will connect all the machines and run the full production line to ensure the stable running in customers' factory



Our Service
SGS approval PLC System PBT Plastic Dryer Machine 4
1.We will provide testing if the customer comes to visit factory to see the machine.
2.We will provide detail machine technical specification ,electric diagram,installation,operation manual and all the documents which customer needed for clearing customs and using the machine.
3.We will provide engineers for helping installation and training the workers at customer's site.
4.Spare parts are available when they are needed .Within warranty time,we we will provide spare parts free,and over warranty time,we will provide spare parts with factory price.
5.We will provide technical support and repair service in the whole lifetime .
