70ppm Polyester Masterbatch PET Crystallization Machine

USD 10,000-USD30,000
70ppm Polyester Masterbatch PET Crystallization Machine
Features Gallery Product Description Request A Quote
Applied For: Polyester Asterbatch,PET Masterbatch,Plastic Masterbatch
Crystallization Time Need: 20mins Or Adjustable By Material Requirement
Drying Time: 20mins Or Adjustable By Material Requirement X
Final Moisture: 10-70ppm
Colour Change: The Drum With The Simple Mixing Elements Has No Hidden Spots
How To Clean: Easily Cleaning With A Vacuum Cleaner Or Compressed Air
No Clumping: Rotary Drum Design To Avoid Any Clumping
Certificate: CE,IS09001, SGS
Patent: China Patent
Delivery Time: 30 Working Days
Package: Factory Standard Package Or Customized
High Light:

PET Crystallization Machine


Crystallization Masterbatch Machine


70ppm Crystallization Machine

Basic Infomation
Place of Origin: CHINA
Brand Name: LIANDA
Certification: CE,SGS,ISO9001
Model Number: LDHW-200
Payment & Shipping Terms
Packaging Details: Factory standard package or customized package
Delivery Time: 40 working days
Payment Terms: T/T, L/C, Western Union
Product Description


Polyester Masterbatch crystallizer, PET Crystallization machine,Fast change colour, No clumping, ,Infrared Rotary dryer






Heating.Heating granules and regrind material prior to further processing (e.g. PVC, PE, PP,…) inter alia to improve the throughput in the extrusion.

Crystallization.Crystallisation of PET (Bottleflakes, granules, flakes), PET masterbatch, CO-PET, PBT, PEEK, PLA, PPS, etc.

Drying.Drying of plastic granules, and –ground material (e.g. PET, PBT, ABS/PC, HDPE, LCP, PC, PP, PVB, WPC, TPE, TPU) as well as other free-flowing bulk materials.

Coating.Coating of adhesives (e.g. Hot melt, EVA+lime,…)

High input moisture.Drying processes with high input moisture >1%.

Diverse.Thermal processes for the removal of rest oligomeren and volatile components.

70ppm Polyester Masterbatch PET Crystallization Machine 0


What Can We Do For You ?


70ppm Polyester Masterbatch PET Crystallization Machine 1




70ppm Polyester Masterbatch PET Crystallization Machine 2

1. Material Feeding 2. Rotary Drying and Crystallization 3. Discharging



Our Advantage



Infrared Crystal Dryer


Conventional Crystallizer

Easy to clean

The drum can be opened completely,no hidden spots and can be cleaned easily with a vacuum cleaner

Have to be completely disassembled,cleaned and fixed
2 Rotary drying system, its rotating speed can be increased as high as possible to get an excellent mixing of pellets. It is good in agitation, the masterbatch will not be clumped Poor agitation,easy to be clumped
3 Can satisfy different type of Masterbatch (Drying temperature and time can be adjustable by the property of raw material) The drying temperature is fixed
4 Crystallization time 15-20mins depends on the material kind Need 4-6 hours or more

Save about 40% energy consumption compared to conventional dehumidifier





70ppm Polyester Masterbatch PET Crystallization Machine 3


Contact Us


70ppm Polyester Masterbatch PET Crystallization Machine 4


70ppm Polyester Masterbatch PET Crystallization Machine 5


● In order to ensure the accuracy of each part, we are equipped with a variety of professional processing equipment and we have accumulated professional processing methods over the past years.
● Each component before assembly needs strictly control by inspecting personnel.
● Each assembly is in charged by a master who has working experience for more than 20 years
●After all the equipment are completed, we will connect all the machines and run the full production line to ensure the stable running in customers' factory

Our Service
SGS approval PLC System PBT Plastic Dryer Machine 4
1. We will provide testing if the customer comes to visit factory to see the machine.
2. We will provide detail machine technical specification ,electric diagram,installation,operation manual and all the documents which customer needed for clearing customs and using the machine.
3. We will provide engineers for helping installation and training the workers at customer's site.
4. Spare parts are available when they are needed .Within warranty time,we we will provide spare parts free,and over warranty time,we will provide spare parts with factory price.
5. We will provide technical support and repair service in the whole lifetime .
