50hz 3 PHASE 20 Mins PLA Infrared Crystal Dryer

USD 10,000-USD30,000
50hz 3 PHASE 20 Mins PLA Infrared Crystal Dryer
Features Gallery Product Description Request A Quote
Drying Temperature: Can Be Adjustable By Material Property
Drying Time: 20mins (can Be Adjustable By Moisture Need)
Power Consumpron: Only 45% Of Conventional Dehumidifier
Processing: Dry And Crystallization At A Time
Heater: Infrared Lamps
Power Source: 380V 50hz 3PHASE Or Customized
Control System: Siemens PLC
High Light:

20 Mins Infrared Crystal Dryer


PLA Infrared Crystal Dryer


50hz Infrared Crystal Dryer

Basic Infomation
Place of Origin: CHINA
Brand Name: LIANDA
Certification: CE,SGS,ISO9001
Model Number: LDHW
Payment & Shipping Terms
Packaging Details: Factory standard package or customized package
Delivery Time: 40 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Product Description

PLA crystallization and drying 20 mins in one step, PET Pre Crystallization Dehumidifying Dryer


PLA is kind of very sensitive temperature material. PLA is a hygroscopic thermoplastic that easily absorbs water from the


Even small amounts of moisture will hydrolyze PLA in the melt phase, reducing molecular weight and causing loss of properties. This can cause sheet brittleness, internal holes, sagging of the web at the die exit, or other process and quality problems. With PLA, proper drying is not optional. It is absolutely essential. Resin manufacturers recommend that PLA be dried less than 250 ppm before processing. In fact, moisture levels below 200 ppm may be needed in order to ensure a reasonable safety margin and, in some cases, moisture levels below 50 ppm are recommended.


50hz 3 PHASE 20 Mins PLA Infrared Crystal Dryer 0


Infrared dryer LIANDA Made can be used for  drying a variety of plastic pellets, such as PBAT,APET, GPET, CPET, PLA, HIPS, PE, ABS, EVA ,PC, PEEK, PPS, PTFE, PEEK, TPU, TPE e.g.


We got German Patent on Infrared crystal dryer ( IRD) in 2008, and patent number is ZL201110032787.6


Infrared drying technology offers the ability to dry and crystallize materials in minutes, compared to hours with conventional drying equipment which reduces change over times significantly and reduces energy consumption at almost 45-50%, Also Infrared drying technology changes in moisture at beginning will dry pellets gently to a uniform degree within minutes, the final moisture can be 30-50ppm.


Our Advantage



Infrared Crystal Dryer


Conventional Crystallizer

Easy to clean and change color

The drum can be opened completely,no hidden spots and can be cleaned easily with a vacuum cleaner

Have to be completely disassembled,cleaned and fixed
2 Rotary drying system, its rotating speed can be increased as high as possible to get an excellent mixing of pellets. It is good in agitation, the masterbatch will not be clumped Poor agitation,easy to be clumped
3 Can satisfy different type of Masterbatch (Drying temperature and time can be adjustable by the property of raw material) The drying temperature is fixed
4 Crystallization time 15-20mins depends on the material kind Need 4-6 hours or more

Save about 40% energy consumption compared to conventional dehumidifier




How Lianda Infrared dryer to crystallize

50hz 3 PHASE 20 Mins PLA Infrared Crystal Dryer 1


50hz 3 PHASE 20 Mins PLA Infrared Crystal Dryer 2






50hz 3 PHASE 20 Mins PLA Infrared Crystal Dryer 3



● In order to ensure the accuracy of each part, we are equipped with a variety of professional processing equipment and we have accumulated professional processing methods over the past years.
● Each component before assembly needs strictly control by inspecting personnel.
● Each assembly is in charged by a master who has working experience for more than 20 years
●After all the equipment are completed, we will connect all the machines and run the full production line to ensure the stable running in customers' factory



Why choose us

1. We are professional manufacturer of plastic recycling and have professional technical team, focus on provide high quality equipment and good service for customer.

2. Our plant with area of 7600 square meters, 62 employees. All skill workers have professional skills certificates.

3. We have professional production QC team to ensure the machine manufacturing quality.

4. All equipment are running test before shipment.

5. During customer visit, we can take customer to our customer ‘s factory to looking machine working.

6. We imported Germany PET infraraed technology and got production patent in China on 2008. On this basis, research and development and improvement have solved the problem of material leakage in the production process.


Our Service
50hz 3 PHASE 20 Mins PLA Infrared Crystal Dryer 4
1.We will provide testing if the customer comes to visit factory to see the machine.
2.We will provide detail machine technical specification ,electric diagram,installation,operation manual and all the documents which customer needed for clearing customs and using the machine.
3.We will provide engineers for helping installation and training the workers at customer's site.
4.Spare parts are available when they are needed .Within warranty time,we we will provide spare parts free,and over warranty time,we will provide spare parts with factory price.
5.We will provide technical support and repair service in the whole lifetime.


50hz 3 PHASE 20 Mins PLA Infrared Crystal Dryer 5
