100kw Wannan Motor Plastic Bottle Recycling Machines

1set
MOQ
100kw Wannan Motor Plastic Bottle Recycling Machines
Features Gallery Product Description Request A Quote
Features
Specifications
Automatic Grade: Automatic,Semi-Automatic
Condition: New
Warranty: 1 Year
Application: Plastic Recycling,PET Flakes Bottle Washing,pet Bottle Recycling,EPS Recycle System
After-sales Service Provided: Engineers Available To Service Machinery Overseas
Production Capacity: 300-2000kg/h
Material Processed: Bottle Flakes,waste PET Bottle
Plastic Type: PET,PP PE HDPE LDPE
Final Product: Clean Flakes/scraps,Clean Flakes,Dry PET Flakes
Product Name: Plastic Recycling Machine,pet Bottle Recycling Machine
Keywords: Bottle Recycling Machine,PET Plastic Bottle Recycling Production Line,High Efficiency,energy-saving
Name: Plastic Recycling Equipment,Pet Bottle Recycling Machine,PET Bottle Recycling Machine/plastic Recycling Plant
Material: Plastic Bottle
Motor: Wannan Motor,Siemens
High Light:

Wannan Motor Plastic Bottle Recycling Machines

,

100kw Plastic Bottle Recycling Machines

Basic Infomation
Place of Origin: CHINA
Brand Name: LIANDA MACHINERY
Certification: CE,ISO9001,SGS
Model Number: LDRC-1000
Payment & Shipping Terms
Packaging Details: Factory standard package /customized package
Delivery Time: 45working days
Payment Terms: T/T, L/C, Western Union
Product Description

Waste PET Bottle Cutting ,Washing ,Drying Recycling machine line


Used to recycle pet bottle, water bottle, Sprite bottle, cola bottle, juice bottle, pet sheet, pet packing container, pet strap,pet film and so on. According to the final usage of PET flakes, We supply 3 grade bottle flakes :
- Bottle to bottle grade, Food Standard
- Yarn/filament grade
- conventional grade



Waste PET Bottle Cutting , Washing ,Drying Recycling machine


100kw Wannan Motor Plastic Bottle Recycling Machines 0

Model

Capacity
KG/H

Power

KW

Water-consumption

M3/H

Flake Grade
LDJXC-1000 800-1000 70 3 Cold washing
LDJXH-1000 120 5

Hot wash
PET Flake Staple fiber

LDJXS-1000 130 6

Hot wash
Filament fiber

LDJXC-1500 1300-1500 85 4 Cold washing
LDJXH-1500 140 7

Hot wash
PET Flake Staple fiber

LDJXS-1500 150 8

Hot wash
Filament fiber

LDJXC-2000 1800-2000 100 5 Cold washing
LDJXH-2000 160 8

Hot wash
PET Flake Staple fiber

LDJXS-2000 180 10

Hot wash
PET Flake Staple fiber

Above are the standard model of our company, if you have any special requirement, please contact us




Features:
1• Labor saving. The bale opening and feeding system we provide will equally feed the material.
2• You can use the manually sorting system to selecting out different color bottles and non-PET material
(we also supply automatic bottle sorting system,but the cost higher)
3• The Line With Automatic Metal detector which used to take out any kind of metal from the PET bottles
4• Crusher Grinder machine with water crushing ,Use D-2 blade by USA Standard
5• Hot washing tank with electric heating water or by steam boiler system
6• High speed friction washing dewatering machine and drying system will insure the final PET flakes moisture <1%
7• by Zig zag dust separator machine,it will remove the final labels from the flakes to guarantee the PVC content.
8.The line with automatic bottle color,material sorting,insure the pet flakes purify
9.By Automatic scale weight system,easy for worker precision packaging and weight


Machine photos for reference

1. Bale opener/De-baler is made up of Automatic lift and De-baler. The Automatic lift will convey the PET Bottle Bales to De-baler to break the bales to bulk bottles.
Adopt specialized hard face gearbox.

100kw Wannan Motor Plastic Bottle Recycling Machines 1


2. Belt conveyor + Label remover

100kw Wannan Motor Plastic Bottle Recycling Machines 2

2.1 Blade material is alloy steel, the blade teeth are replaceable. Design of Arc Knife, the space between Rotary blades and Stable blades will be always the same to avoid breaking the PET Bottle necklace while Rotary blades and Stable blades rotating at 360 degree (The necklace is the best part in the bottle, the viscosity is the highest )
the viscosity is the highest

100kw Wannan Motor Plastic Bottle Recycling Machines 3

2.2 There are limit switch installed on the inspecting hole. The machine will be stopped while opening the door, to keep sure safety producing


100kw Wannan Motor Plastic Bottle Recycling Machines 4

2.3 Designed of inspecting window for checking and maintainance the machine

100kw Wannan Motor Plastic Bottle Recycling Machines 5

3. Sorting table

100kw Wannan Motor Plastic Bottle Recycling Machines 6
3.1 With chutes to connect to crusher, to feed materials into crusher directly.
3.2 Equipped with hooks
3.3 With chutes and containers and a place for the supervisor at the end of the belt.
3.4 Handrail for the people not below 100cm measured from platform bottom


4. Crusher

100kw Wannan Motor Plastic Bottle Recycling Machines 7

4.1 Blades frame The blade of plastic bottle crusher using claw structure which with strong adhesion for hollow thin-wall products and sheet

100kw Wannan Motor Plastic Bottle Recycling Machines 8


4.2 Blade material can be customized: 9CrSi ( Russia material),SKD-11 (Japan Material), D2 etc.
4.3 Crusher open Adopt Hydraulic open. It can be opened and closed easily to allow changing of blades to improve the working efficiency

100kw Wannan Motor Plastic Bottle Recycling Machines 9

5. Steam washer
Hot washing for removing glue, oil, dirty. There are special design for discharging PP/PE labels and caps.
The steam washer1 is designed deep enough for separating PP/PE Labels/cap from PET; The depth of steam washer 2 is lower than steam washer because most PP/PE Labels/caps is discharged by Steam washer 1

100kw Wannan Motor Plastic Bottle Recycling Machines 10

  • With quantitative feeder for chemical detergent
  • Adopt Asbestos for insulation layer, thickness is 40mm

100kw Wannan Motor Plastic Bottle Recycling Machines 11

6. Floating washer
6.1 For Separating PET from PP/PE Caps and Labels;
6.2 Removing the dust and dirty after the High speed friction washer
(Because of the property of the plastic -- PP/PE will be floating on the water; PET will be down in the water)
6.3To middle PH Value

100kw Wannan Motor Plastic Bottle Recycling Machines 12


7. High speed friction washer
For removing the dirty on the surface of the flake

100kw Wannan Motor Plastic Bottle Recycling Machines 13


7.1 With the design of dirty water dewatering. To keep water clean on the next step washing processing. Enlonger the water using
7.2 Adopt NSK bearing
7.3 Rotating speed 1200rpm
7.4 With the Americal wearing material on the surface of the screw blades for longer working life
100kw Wannan Motor Plastic Bottle Recycling Machines 14

8. Horizontal dewatering machine ----Final moisture can be 1.8%

100kw Wannan Motor Plastic Bottle Recycling Machines 15

8.1 Adopt European standard belt wheel and SKF Bearing

100kw Wannan Motor Plastic Bottle Recycling Machines 16

8.2 Adopt Americal wearing material to enlonger the working life of screw

100kw Wannan Motor Plastic Bottle Recycling Machines 17

9. Label separator/Zigzag separator to separate PP/PE Labels from PET Flake and remove plastic powder

100kw Wannan Motor Plastic Bottle Recycling Machines 18
